Thermalright Wonder Vision 360 UB ARGB White
Thermalright Wonder Vision 360 UB ARGB White is a white Hydro Cooling AIO liquid cooler built around a 360 mm radiator and a large integrated display. It combines liquid cooling hardware with a visual front panel, making it a distinctive option for systems that need broad socket support and a cleaner white finish.
Cooling layout
The cooler uses a 360 mm radiator made of aluminum, paired with three TL-UB36W fans in a standard radiator configuration. The radiator measures L403 mm x W120 mm x H27 mm, so case clearance matters, especially around the top area and memory slots.
- Cooling Type: Hydro Cooling / AIO liquid cooler
- Radiator Size: 360 mm class
- Radiator Material: Aluminum
- Radiator Dimensions: L403 mm x W120 mm x H27 mm
Display and pump assembly
The pump unit includes a 6.67-inch display with a 2400 x 1080 resolution. The pump dimensions are L120.1 mm x W80 mm x H107 mm, and the pump is rated up to 6400 RPM ±10% with 12V DC power.
This setup places the display and pump at the center of the cooler’s design, while keeping the radiator and fan assembly separate for chassis mounting.
- Display: 6.67-inch, 2400 x 1080 screen
- Pump Dimensions: L120.1 mm x W80 mm x H107 mm
- Pump speed: up to 6400 RPM ±10%
Fans and connection details
The included TL-UB36W fans are rated for up to 2150 RPM ±10%, 69 × 3 CFM airflow and 27 dBA maximum noise. Thermalright lists a 4-pin PWM fan connector and a 3-pin 5V ARGB lighting connector, which keeps fan control and lighting wiring straightforward.
The fan set uses S-FDB V2 Bearing, a detail that may matter to buyers comparing fan hardware rather than just radiator size.
- Fans: TL-UB36W, 3-fan radiator configuration
- Maximum Fan Speed: 2150 RPM ±10%
- Maximum Fan Airflow: 69 × 3 CFM
- Maximum Fan Noise: 27 dBA
- Fan Connector: 4-pin PWM
- Lighting Connector: 3-pin 5V ARGB
Socket support and fitment
This cooler supports Intel LGA115X, 1200, 1700, 1851, 2011 and 2066, as well as AMD AM4 and AM5. It is designed for a wide range of desktop builds, but the radiator thickness and overall height still require enough chassis space.
Thermalright also notes that tall memory modules and cooler height clearance should be checked during installation.
- Socket Compatibility: Intel LGA115X / 1200 / 1700 / 1851 / 2011 / 2066; AMD AM4 / AM5
- Compatibility: Intel LGA115X / 1200 / 1700 / 1851 / 2011 / 2066; AMD AM4 / AM5
Practical notes
The white color helps keep the cooler visually consistent in light-themed builds. The combination of a 360 mm radiator, three fans and a large display makes it a feature-rich AIO, while the broad socket list gives it flexibility for current Intel and AMD platforms.
Key points:
- White finish
- 360 mm radiator
- 6.67-inch 2400 x 1080 display
- Three TL-UB36W fans
- 4-pin PWM and 3-pin 5V ARGB connectors
